CGF Type Water Bottling Machine For Drinking Water Packinng Plant

CGF Type Water Bottling Machine For Drinking Water Packinng Plant

CGF Type Water Bottling Machine For Drinking Water Packinng Plant
CGF Type Water Bottling Machine For Drinking Water Packinng Plant
CGF Type Water Bottling Machine For Drinking Water Packinng Plant
Product Details:
Place of Origin: Zhangjiagang city
Brand Name: DMK
Model Number: CGF 18-18-6
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export packing
Delivery Time: 30 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per year
Contact Now
Detailed Product Description
Name: Bottle Water Bottling Machine Electric Supply: 380V 50HZ(customized)
Machine Capacity: 6000 Bottles Per Hour(500ml Plastic Bottle) Machine Model: CGF 18-18-6
Rinsing Head: 18 Pcs Filling Head: 18 Pcs
Capping Head: 6 Pcs Machine Size: 2400*1830*2400mm
High Light:

CGF Type Water Bottling Machine

,

18pcs Rinsing Head Water Bottling Machine

,

380V 50HZ Water Bottling Machine

Small Water Bottling Machine for Drinking Water Packinng Plant

Water bottling machine description:



This machine is widely used automatic bottled water filling and capping machine, including water rinsing, water filling and cap screwing 3 main functions, and it is designed for plastic bottles, and the filling machine be connected with bottle making machine by air conveyor directly, which is an idead machine special designed for water plant, flavored water plant and various types non-carbonated drinks production plants. Accoridng to customer's deamnds, we can also make this machine suitable for glass bottles or other types containers.This CGF type bottle water filling machine has different models with different production capacity, from 2000 bottles per hour to 20000+bottles per hour, we will give suitable guidance accoridng to customer's situation and our experience.





Water bottling project line:


1. Water filtration: RO water purification machine / UF mineral water filtration machine.



2. Bottle making: Full automatic bottle blow machine or Semi automatic bottle blow machine.



3. Bottle water filling: Bottle washing filling and capping machine.



4. Labeling machine: Shrink sleeve labeling machine or Sticker labeling machine.



5. Date printing: Laser type date marking or ink type date marking machine.



6: Package the bottle water: Full automatic shrink wrapping packing machine or Semi automatic shrink wrapping packing machine / Carton box packing machine



Water bottling machine parameters:



Item                 CGF8-8-3    CGF12-12-5  CGF18-18-6  CGF24-24-8  CGF32-32-10

Capacity

bottles per hour

2000-3000 3000-4000 5000-6000 8000-10000 10000-12000

Suitable bottle

diameter

50-90mm

200-2000ml

Rinsing pressure

kg/cm2

2-3

Machine weight

KG

1500 2500 3500 4000 5000

Machine size

L*W*H (mm)

1900*1600

*2400

2400*1600

*2400

2400*1830

*2400

3100*2200

*2400

3600*2500

*2400































Water bottling machine component :



No



Name

Details
1       Product conveyor It helps transfter bottles between each machines auyomaticall, which can save a lot of labor cost, and reach higher production speed.
2 Air conveyor This is used to transfter empty bottles between bottle making machine(or bottle sorting machine, manual feeding table) to filling machine, empty bottles will be transferred by air, which can reduce second touch.
3 Automatic cap feeding system It transfer caps into cap tunnels, and caps will be arranged in lines to get into cappinng station.
4 Motors This is power system to give power to conveyor belt, we use reduction motors to ensure the smooth operation of the conveyor belt.





CGF Type Water Bottling Machine For Drinking Water Packinng Plant 0CGF Type Water Bottling Machine For Drinking Water Packinng Plant 1



Thanks!

For more information please contact us!
