2000bph 3.1kw Hot Liquid Filling Machine For Fruit Juice 8 Filling Heads

I'm Online Chat Now

2000bph 3.1kw Hot Liquid Filling Machine For Fruit Juice 8 Filling Heads

small.img.alt small.img.alt small.img.alt

Large Image :  2000bph 3.1kw Hot Liquid Filling Machine For Fruit Juice 8 Filling Heads

Product Details:

Place of Origin: Zhangjiagang city
Brand Name: DMK
Model Number: RCGF8-8-3

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Standard export packing
Delivery Time: 30 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100 sets per year
Detailed Product Description
Name: Juice Bottling Machine Capacity: 1500-2000 Bottles Per Hour(500ml Bottle)
Material: Stainless Steel Power: 3.1KW
Filling Type: High Temperature Filling Size: (L*W*H)1900*1600*2400mm
Function: Rinsing Filling Capping 3 In 1 Filling Head: 8 Heads
High Light:

juice bottle filling machine


hot liquid filling machine


2000bph Liquid Filling Machine

2000BPH PET Plastic Bottle Hot Filling Machine for Fruit Juice Juice Bottling Machine

Equipment description:


This series of juice bottling machine combines washing, filling, sealing 3 functions as one unit, suitable for all kinds of juice drinks, tea drinks and other beverage hot filling production,only need to replace a small number of parts, this machine can also be used for pure water, mineral water production.This machine adopts advanced micro - negative pressure gravity filling principle,which has filling fast, stable, accurate, with a perfect material return system, can also achieve independent air return when the beverage return, no liquid contact, reduce the material secondary pollution and oxidation.This function satisfy the requirements of under 95 ℃ hot filling, liquid materials inlet and outlet of the filling valve without health dead Angle, this machine is equipped with automatic CIP cleaning device at the same time, the whole production line equipment to wash, block is equipped with the bottle before RO water flushing device, to ensure that drinks and bottle no moldy phenomenon, using magnetic torque type screw LIDS, realize cover, screw cap function. Capping moment stepless adjustable, with constant torque capping plastic cap. The machine adopts advanced technology such as man-machine interface touch screen control, PLC computer program control and frequency converter control. It has the functions of automatic control of cover supply system, self-coordinating detection of filling temperature, high temperature alarm of materials, low temperature shutdown and automatic backflow, no bottle without cover, bottle waiting, and shutdown without cover


Equipment parameters:


Machine model: RCGF 8-8- 3

Rinsing head: 8 pcs rinsing nozzel.

Filling head: 8 pcs hot filling valve.

Capping head: 3 pcs plastic screw capping head

Production output: 1500-2000 bottles per hour

Suitable bottle diameter: 50-90mm

Suitable bottle volume: 250-1500ml(can be customized)

Filling temperature: 85-92℃

Machine size:About 1900*1600*2400mm

Machine weight: About 1500KG


Product features:


No Details
1 It employs single cavity plunger type of fixing filling volume technique and equipped with perfect temperature control system
2 It equipps reverse-flow system to make sure the filling quality, which can avoid the steam effect from high temperature juice
3 Automatic cleaning system is equipped, it can connect to CIP cleaning system directly to clean the filling tank and valve, which is good for machine service life.
4 Each machine element that contacts with the liquid is made of high quality stainless steel and food-grade rubber.

Centralized lubricating oil for easy maintenance and maintenance.


Details description:

No Details
1 Safe protective devices ensure safety of operator and machine.
2 Magnetic torsion type screw capper ensures the tightness of the cap and avoids bottle damage.
3 The module of screw capper ensures the tightness of the cap and avoids bottle damage.
4 Slight negative-pressure gravity circumfluence filling system increases juice filling accuracy and reduces contamination.
5 Unique control mechanism keeps circumfluence volume below 5%.
6 Airtight valve made of non-plastic material prevents worn-out particles from dropping into bottles adversely affecting product quality.
7 High efficient clean air filter circulation system ensures high sanitary requirements.
8 Low overall machines noise that is comparable to any internationally known equipments in its class.
9 Self-lubricationg system imported from America provides continuous smooth operation.
10 The machine can be connected with UHT, CIP control center and bottle-invert sterilizer.
11 The core parts of machine employs PLC+, frequency convertor+ and human-machine interface control technology.

2000bph 3.1kw Hot Liquid Filling Machine For Fruit Juice  8 Filling Heads 0
